RBC6 Replacement Kit 2pcs 12V 12Ah GP12120F2w/ harness kit
Original price was: USD 260.77.USD 169.50Current price is: USD 169.50.
CSB GP12120 F2 SEALED LEAD ACID RECHARGEABLE BATTERY_x000D_
General purpose battery for a range of standby applications_x000D_
High quality battery sealed leak proof maintenance free design_x000D_
Popular for use in UPS systems emergency lighting fire and security alarms_x000D_
Rated for up to 5 years life in standby or 260 cycles at 100% discharge_x000D_
Specification_x000D_
Manufacturer: CSB_x000D_
Battery Type Number: GP12120F2_x000D_
Battery Type: VRLA Sealed Lead Acid Battery_x000D_
Voltage: 12V_x000D_
Capacity Rating: 12Ah_x000D_
Dimensions: 151mm x 97mm x 94mm_x000D_
Weight: 3.67Kg_x000D_
Terminal: F2 Faston terminals (0.25″)_x000D_
Commodity Code / HS Code – 85072020_x000D_
Country of Origin (COO) – VN, Vietnam
| Specification |
| Cells Per Unit | 6 |
| Voltage Per Unit | 12 V |
| Capacity | 12 Ah @ 20hr-rate to 1.75V per cell @ 25°C (77°F) |
| Weight | Approx. 3.67kg. (8.09 lbs.) |
| Maximum Discharge current | 150/180A (5sec.) |
| Internal Resistance | Approx. 16.7 mΩ |
| Operating Temperature Range | Discharge：-15℃~50℃(5°F~122°F) Charge：-15℃~40℃(5°F~104°F) Storage：-15℃~40℃(5°F~104°F) |
| Nominal Operating Temperature Range | 25°C ± 3°C (77°F ± 5°F) |
| Float charging voltage | 13.5 to 13.8 VDC/unit Average at 25°C (77°F) |
| Recommended Maximum Charging current limit | 3.6 A |
| Equalization and Cycle Service | 14.4 to 15.0 VDC/unit Average at 25°C (77°F) |
| Self Discharge | It should be more than 75% of the capacity that before storage after stocked for 6 months at ambient temp. 25℃ |
| Terminal | F1/F2-Faston Tab187/250 |
| Container Material | ABS(UL94-HB) & Flammability resistance of(UL94-V0) can be available upon request. |
| Weight | 3.67 kg |
|---|---|
| Dimensions | 15.1 × 9.8 × 9.41 cm |
| Battery Type | Valve regulated Lead Acid Maintenance Free Battery |
| Country of Origin | Netherlands, Europe |
| Manufacturer | CSB Energy Technology Co., Ltd |
| Battery Volts | 12 Volts |
| Part No | RBC6 |
| Brand | CSB |
| Warranty | 12 Months Limited Warranty against Manufacturers defects |
| Model | CSB-1003 |
