SUPREME SPX3380 – FX – 80kVA/80kW Extreme Power, Power Smart UPS, On-Line, Tower, 230V 380V 415V, w/Internal Maintenance Bypass & Parallel Capability, 3 Phase In / 3 Phase Out, Power Factor of 1.0
Original price was: USD 46,540.50.USD 23,270.25Current price is: USD 23,270.25.
• Wide input voltage and frequency range with high grid adaptability and prolong battery life.
• Advanced IGBT and three level technology, Low harmonic, high efficiency, effectively energy-saving.
• Advanced and dual DSP control prevents single failure point and increase performance.
• High power density design, which small footprint on 100KW only 0.38m² saving the cost of Shipping, Delivery, and installation.
• High input power factor up to 0.99 and low Input THDi: < 3.0% at full load, much less grid pollution and costs
• AC/AC efficiency up to 96.5% and 30% load up to 95% efficiency reduces heat dissipation and limits power consumption costs
• Integrated with input, output, bypass breaker and manual bypass switch for better protection of the system.
• Separate internal air channel which hot air drives directly towards heat sink without distressing the PCB's and other internal sensitive components, improving the components service life and UPS reliability
• High overload capacity on inverter and bypass
• Intelligent fan control and redundant design: 15% load can be driven when 2 fans fail and 40% load when 1 fan fails
• All-round conformal coating to all PCB boards, protect electronics from environmental affection and corrosion.
• Lithium battery compatible
• AC/AC efficiency up to 96.5% and 30% load up to 95% efficiency reduces heat dissipation and limits power consumption costs
• ECO mode efficiency up to 99.2% lead to significant cost reduction
• W-ECO mode could reach 98.5% efficiency, THDi below 5% and transfer time below 4ms to reduce TCO.
• Fault Trace Management (FTM) for convenient failure analysis (waveform record before & after of the fault point for 200ms) which easily figure out faulty point.
• 3 stage battery charging prolong the service life of batteries
• Intelligent battery management and multiple setting, ±14~±24 pcs batteries per string allow customers to get the faulty battery out instead of replacing it
• Key components pre-alarm function which precaution the system fault and remind service for key components, like capacitor, fan.
• Full asset management record the spare parts replacement, timeline and service people.
• User-friendly double physical ON/OFF button design to avoid false operation.
• User-friendly graphical interface with Single-line mimic diagram showing system status.
• Colorful 4.3" and 7" touch screen with LED Indicators, ensure comprehensive and visualized information display.
• Multicolor LED bar allowing quick and easy detection of the system status and simplified troubleshooting.
• Multi-language build-in display
| MODEL | SPX3380 | ||
|---|---|---|---|
| INPUT | |||
| Voltage (Vac) | 380/400/415 (138~485 L-L) | ||
| Frequency (Hz) | 40~70 | ||
| Power Factor | ≥0.99 | ||
| Phase | 3φ4W+PE | ||
| THDi at full linear load | <3% (linear load) | ||
| BYPASS | |||
| Bypass Voltage (Vac) | 380/400/415 | ||
| Voltage Range | -20% (-10%/-15%/-30%selectable)/+15% (10%/20%/25% selectable) | ||
| Overload | ≤130%: long run;130%< load ≤150%: 5min; 150%< load ≤200%: 1s; 200%< load≤300%: 100ms; >300%: immediately. | ||
| OUTPUT | |||
| Capacity (kW) | 60 | 100 | 200 |
| Power Factor | 1 (0.5 leading to 0.5 lagging) | ||
| Voltage (Vac) | 380/400/415±1% | ||
| Frequency (Hz) | 50/60±0.1% (Battery mode) | ||
| Phase | 3φ4W+PE | ||
| Three Phase Difference | ≤1% | ||
| Waveform | Pure sine wave, THDv<1% at linear load,THDv<3% at non-linear load | ||
| Transfer Time (ms) | 0 | ||
| AC-AC Efficiency | up to 96.5% | ||
| Overload | 101-105% Long run, 106-110% load for 60 minutes,111%-125% load for 10 minutes, 126%-150% load for 1 minute, over 150% load transfer to bypass | ||
| BATTERY | |||
| Battery Voltage (Vdc) | ±192(±168 ~±288 adjustable) | ±240(±168 ~±288 adjustable) | |
| Battery Type | External | ||
| Charging Current (A) MAX | 30 | 60 | |
| GENERAL | |||
| Communication Interface | RS232, RS485, MODBUS, dry contact( BMS,SNMP, expend dry contact card are optional in slot) | ||
| Display | 4.3" Touch screen+LED+LED bar | 7" Touch screen+LED+LED bar | |
| Alarm | AC input abnormal, low battery, overload, failure | ||
| Protection | Output short-circuit, overload, over-temperature, battery low voltage, output over/low voltage | ||
| Noise (dB) | <65 | <70 | |
| Altitude(m) | 0-2000 no derate. 2000-3000 m derate power by 1 % per each 100 m increase | ||
| IP | IP20 | ||
| Working Temperature (°C) | 0 ~ 40 no derate,40~50 auto derate. | ||
| Relative Humidity | 0 ~ 95%, no condensation | ||
| Dimension (W×D×H)(mm) | 400×960×1200 | 600×1000×1600 | |
| Weight (kg) | 145 | 161 | 312 |
| Weight | 145 kg |
|---|---|
| Dimensions | 40 × 96 × 120 cm |
| Brand | SUPREME |
| Country of Origin | Canada |
| Manufacturer | Supreme North America Corporation |
| Type of Phase | Three Phase In / Three Phase Out |
| Type of UPS | Online UPS – 3Phase |
| Voltage | 415V |
| Rating | 80KVA |
| Model | SPX3380 – FX- 80KVA |
| Warranty | 2years Manufacturers Warranty for the UPS, 1year Warranty on batteries |
