D-Link DMC-300MSC 10/100Base-TX Fast Ethernet Twisted-pair to 100Base-FX Fast Ethernet Fiber
Original price was: USD 67.15.USD 53.72Current price is: USD 53.72.
Part Number:
DMC-300SCThese
converters convert 10/100Mbps 10BASE-T/100BASE-TX Fast Ethernet
twisted-pair signals to 100BASE-FX Fast Ethernet multi-mode fiber
signals.
Maximum fiber cable distance is 2km. 1 RJ-45 twisted-pair port and 1 fiber port are provided.
– DMC-300SC: the fiber port on this media converter is the SC connector
General features
Interface
Number of Ports
• 1 x 10/100BASE-TX RJ-45 port
• 1 x 10/100BASE-FX SC port
Standards
• IEEE 802.3 for 10BASE-T/F
• EEE 802.3u for 100BASE-TX/FX
Data Transfer Rate
• Ethernet: 10 Mbps/20 Mbps (halfduplex/full-duplex)
• Fast Ethernet: 100 Mbps/200 Mbps (half-duplex/full-duplex)
Duplex Mode
• Half-duplex/full-duplex
Media Types
• 10BASE-T: 2-pair Cat. 3/4/5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)
• 10/100BASE-TX: 2-pair Cat. 5/5e, Unshielded Twisted Pair (UTP) (up to 100 m)
• 100BASE-FX: Multi-mode fiber optic cable with SC connector (up to 2 km)
Media Exchange Interface
• Auto-MDI/MDIX
Functionality
Transmission Mode
• Store-and-forward
Forwarding Rate
• Full wire-speed forwarding rate
Management
• Through the DMC-1000 chassis with the DMC-1002 management module installed
Management Functions
• Fiber port duplex mode
Physical
Diagnostic LEDs
• Power
• Speed (for twisted pair ports)
• Full-duplex/Collision (for twisted pair and fiber ports)
• LINK/ACT (for twisted pair ports)
AC Input
• 5 V/1 A external power adapter
Temperature
• Operating: 0 °C to 40 °C (32 °F to 104 °F)
• Storage: -25 °C to 70 °C (13 ºF to 158 °F)
Humidity
• 10% to 90% RH, non-condensing
Dimensions
• 120 x 88 x 25 mm (4.72 x 3.46 x 0.98 in)
Weight
• 291 g (0.64 lbs)
Fiber Wavelength
• 1310 nm
Supported Fiber Cable Length
• Up to 2 km
Emission Certifications (EMI)
• FCC Class A
• VCCI Class A
• CE Class A
| Model | DMC-300MSC |
|---|---|
| Brand | D-LINK |
| Warranty | 5 years manufacturers against manufacturers defects |
| Manufacturer | Datex Systems, Inc |
| Country of Origin | Taiwan |
